Supco 90340 General Purpose Switching Relay 24 V Coil Voltage Double Pole Double Throw Contacts-New

This Supco 903 series switching relay receives and controls electrical signals for general purpose applications. This switching relay has double pole double throw contacts and is suitable for use in heating air conditioning and refrigeration applications appliance vending machines fan controls and business machines. Specifications ContactsDPDTCoil voltage24 110/12 208/240TerminalspowerContact power ratings12 FLA and 60 LRA at 120V6 FLA 15 RA and 35 LRA at 277VHorsepower: 3/4Contact pilot ratings3 RAHorsepower: 1/10Relay switches (also called an electrical relay or an electrical relay switch) use a small amount of power to control a larger source of power connected to electrical devices such as car motors computers and lighting installations. A basic relay switch has a control circuit with an electromagnetic coil and a load circuit with contacts and a lever. When current flows into the relay switch it moves through the coil and a magnetic field is created which causes the lever in the load circuit to move between contacts either turning the device on or off. In a normally open (NO) relay switch when power is supplied to the relay the load circuit is closed and the power source connected to the relay is turned on. In a normally closed (NC) relay switch when power is supplied to the relay the load circuit is open and the power source connected to the relay is turned off. In other types of relay switches non-moving parts such as transistors or semiconductors can be used as the control circuit to operate the switching mechanism. Relay switches can be controlled with an external switch such as a light switch or they can be connected to an automatically switched power source such as a car ignition. One relay can operate multiple switches and multiple relays can be operated with a single switch with each relay operating independently from the other relays in the system.Supco manufactures test instruments and replacement parts for heating ventilation air conditioning and refrigeration systems. The company founded in 1945 is headquartered in Allenwood NJ.
